40ft HIGH CUBE DAIKIN
REFRIGERATED CONTAINERS

Designed for the transportation of high volume and lighter weight temperature-sensitive perishable cargo

40ft High Cube Daikin

INVERTER TECHNOLOGY – ENERGY EFFICIENT

Our fleet of Daikin ZESTIA and LXE series 40ft High Cube containers provide a cubic capacity of appx 67.4 CBM.  These units are suitable for lighter voluminous temperature sensitive cargo such as flowers and pharmaceuticals.

Daikin refrigerated machinery features a DC converter compressor that helps to change the power supply, providing precise temperature control with low power consumption. This helps reduce operating costs and CO2 emissions.

The high energy-saving performance enables stable temperature control, whilst maintaining the freshness and quality of temperature sensitive and perishable cargo during shipping.

Equipped with a user-friendly unit display and control panel providing basic information such as settings and operation conditions. Active CA provisioned.

The Daikin LXE series has a hot gas system that offers full control and power to vastly improve cargo conditions by providing faster defrosting and dehumidification with less heat escaping into the cargo area.

The 40ft reefers can accommodate 23 Euro pallets (1200 mm x 800mm) and 20 industrial pallets (1200mm x 1000).

Overview

  • High Payload Capacity: Suitable for lighter voluminous cargo.
  • Enhanced Box Durability: Designed for reduced damage and operational costs.
  • Premium ‘T’ Floor Material: Utilizes high-grade Aluminum 6082 T6 for durable flooring.
  • Robust Underfloor & Sill: Features MGSS (Muffler Grade Stainless Steel) components for reinforced structure.
  • Innovative Door Sill Design: Low air leakage (2m3/hr) for heightened energy efficiency.
  • Effective Thermal Insulation: Minimized heat leakage, ideal for temperature-sensitive goods.
  • Certified Excellence: Holds ATO-DLO (Dutch Agrotechnological Research Institute) certification for flower bulb transportation and USDA (United States Department of Agriculture) certification for in-transit cold treatment.
SELECT A MEASUREMENT
DIMENSIONS
External Length12,192 mm
External Width2,438 mm
External Height2,896 mm
Internal
Length
11,588 mm
Internal
Width
2,284 mm
Internal
Height
2,545 mm
Door Opening
Width
2,290 mm
Door Opening
Height
2,596 mm
Cargo Access Height2,503 mm
Cubic
Capacity
67.4 m3
External
Length
40 ft
External
Width
8 ft
External
Height
9 ft 6 ins
Internal
Length
38 ft
Internal
Width
7 ft 6 ins
Internal
Height
8 ft 4 ins
Door Opening
Width
7 ft 6 ins
Door Opening
Height
8 ft 6 ins
Cargo Access Height8 ft 3 ins
Cubic
Capacity
2,380 ft3
WEIGHTS (with Daikin LXE Machinery)
Maximum Gross
Weight
35,000 kgs
Tare
Weight (ex. machinery)
4,160 kgs
Tare
Weight (inc. machinery)
4,580 kgs
Payload
Weight
30,420 kgs
Maximum Gross
Weight
77,160 lbs
Tare
Weight (ex. machinery)
9,170 lbs
Tare
Weight (inc. machinery)
10,100 lbs
Payload
Weight
67,070 lbs
WEIGHTS (with Daikin Zestia Machinery)
Maximum Gross
Weight
35,000 kgs
Tare
Weight (ex. machinery)
4,040 kgs
Tare
Weight (inc. machinery)
4,450 kgs
Payload
Weight
30,550 kgs
Maximum Gross
Weight
77,160 lbs
Tare
Weight (ex. machinery)
8,910 lbs
Tare
Weight (inc. machinery)
9,810 lbs
Payload
Weight
67,350 lbs
HEAT LEAKAGE
Heat Leakage38.5 kcal/deg.c.hr
Heat Leakage38.5 kcal/deg.c.hr
ISO CODE
ISO Code45R1
ISO Code45R1

*Specification data is for reference only. Technical specs may vary subject to manufacturer updates and adjustments.
