- Equipment
Dry Freight ContainersOur intermodal fleet of Standard and High Cube dry freight containers are designed for the watertight and secure transportation of non-perishable dry cargo such as electronics, furniture, apparel, and dry foods.
- Refrigerated Containers
A leading reefer container lessor with a fleet of & 200k units worldwide. Standard and High Cube units equipped with the latest high performance, temperature controlled, energy efficient refrigerated machinery.
- Dry Freight Specials
We offer a diverse fleet of intermodal dry freight specials designed for the safe and secure transportation of heavy breakbulk cargo such as yachts, railcars, lumber, reels & rolls, construction equipment, mining machinery and materials.
- Tank Containers
Seaco is one of the world’s leading tank lessors with a modern and diversified fleet of standard and specialized tanks ranging from T11 to T75 and capacities from 12,000 – 46,000 litres.
SAFE AND EFFICIENT LIQUID TRANSPORT
Seaco can provide a range of 26kl Baffle Tanks fitted with vertical or horizontal baffles in a welded or bolted configuration to help prevent liquid surge when loaded at up to 80% capacity and less than 95% to allow for thermal expansion.
Baffles help improve safety in the anti-slosh performance in tank containers that can be caused by sudden driving conditions such as braking and cornering.
Baffles can also provide the flexibility to ship liquids with a variety of densities within the same tank, thus removing the need to use different capacity Tanks. Tanks in accordance with: UN PORTABLE TANK 11/ADR TANK L4BN, US-DOT, CFR 49, UK-DFT, IMDG, ADR/RID, TC, FRA, AAR600, ISO 1496/3, CSC, TIR, UIC
The authorised Dangerous Goods Advisor should confirm fitness for purpose of any tank and that the cargo is compatible and will not attack the tank vessel. Tank containers are supplied in accordance with a signed lease and Seaco General Trading Terms.
Overview
- Lower Tare Weight: Tank designed with a lower tare weight to optimize a higher payload.
- 3 Cleaning Hatches: To aid ease and thorough cleaning of the tank.
- Walkway: Fitted with a “B” type marine grade aluminium walkway with the option to fit hand rails, to aid safe access around the top of the tank.
- Top Discharge Flange: To facilitate the pressurization of the tank to allow discharge through a pipe from the top of the tank to the bottom inside of the tank.
- Heating: 8 runs providing 10-10.5 sqm of effective heating area suitable for high viscosity and solidifying cargoes during transit.
- Pressure Relief: Fitted with a pressure relief valve to help protect the tank from accidental over-pressure and implosion from unwanted vacuum conditions.
- Bottom Discharge: A 45° univalve bottom discharge assembly is fitted to the drain point of the tank. It is also used for loading and discharging cargo in combination with a second valve.
- Anti-slip Surface Ladder: 304 stainless steel ladder is fitted to the right of the rear of the tank container for the easy and safe access to the top walkway.
| Cargo Capacity | Up to 26,000 ltr |
| Cargo Capacity | Up to 6,870 US gallons |
| Maximum Allowable Working Pressure | 4.0 bar |
| Steam Working Pressure | 4.0 bar |
| Steam Test Pressure | 6.0 bar |
| Relief Valve Set Pressure | 4.4 bar |
| Maximum Allowable Working Pressure | 58 psi |
| Steam Working Pressure | 58 psi |
| Steam Test Pressure | 87 psi |
| Relief Valve Set Pressure | 63 psi |
| Maximum Gross Weight | 36,00 kgs |
| Tare Weight | 4,050 kgs |
| Maximum Gross Weight | 779,365 lbs |
| Tare Weight | 8,929 lbs |
| External Length | 6,058 mm |
| External Width | 2,438 mm |
| External Height | 2,591 mm |
| External Length | 20 ft |
| External Width | 8 ft |
| External Height | 8 ft 6 ins |
| Ambient Temperature Range | -40°C to +65°C |
| Maximum Cargo Temperature | 130°C |
| Ambient Temperature Range | -40°F to +149°F |
| Maximum Cargo Temperature | 260°C |
| Welded or Bolted Configurations Vertical or Horizontal | Multiple Baffles help to prevent liquid surge in partially filled tanks, whilst ensuring of the safe and more stabilised transportation of liquid cargo. |
| Welded or Bolted Configurations Vertical or Horizontal | Multiple Baffles help to prevent liquid surge in partially filled tanks, whilst ensuring of the safe and more stabilised transportation of liquid cargo. |
